Box-type PLC splitter
Designed specifically for the "last mile" of Fiber to the Home (FTTH) and distributed nodes. This integrated encapsulation structure is simple, provides good protection, requires no additional installation accessories, and can be directly placed or fixed in confined spaces such as hallways and junction boxes.
Product Features:
Rugged Encapsulation: Flame-retardant ABS or PC material provides excellent mechanical protection and environmental resistance.
Plug and Play: Precisely tested before leaving the factory, easy to install, greatly saving construction time.
Compact and Lightweight: Compact design suitable for space-constrained applications.
Cost-Effective: Optimized for large-scale terminal deployments, offering highly competitive costs.
Common Specifications:
Split Ratio: 1x2, 1x4, 1x8, 1x16, 1x32
Fiber Type: SMF-28e single-mode fiber
Pigtail Length: Standard 0.5m, 1.0m, 1.5m, customization available
Connector Type: Optional SC/APC, SC/UPC, LC/APC, etc.
| Features | Tray Optic Splitter | Box Type Splitter |
|---|---|---|
| Application Scenarios | Optical Connect Boxes, ODF Distribution Frames, Floor Distribution Boxes |
1. FTTH Terminals 2. Outdoor/Industrial Environments |
| Advantage | Standardized, modular, easy to install and maintain, high port density, flexible | Low cost, simple structure, good protection, easy for direct installation |
| Disadvantage | Requires a matching enclosure or rack for installation | Poor flexibility, difficult to manage, low port density |
Why Choose Our PLC Optical Splitter?
PLC Chip Technology: Utilizes high-quality quartz substrate planar waveguide technology, ensuring low insertion loss, high uniformity, and excellent environmental stability.
Full-Band Support: Widely supports the entire 1260nm to 1650nm band, perfectly compatible with existing and future network standards such as GPON, XG-PON, and EPON.
Automated Production: Fully automated precision manufacturing processes guarantee exceptional consistency and competitive pricing for every splitter.
